ICL7107SCPL - 3 1/2 Digit LCD/LED Display A/D Converter

Producto nº: AD38749
Tu precio: US$11,95
No. de artículos en existencia: 0
Disponibilidad: Solicitado
ICL7107SCPL - 3 1/2 Digit LCD/LED Display A/D Converter

AGOTADO!!

Description:

The Intersil ICL7106 and ICL7107 are high performance, low power, 31/2 digit A/D converters. Included are seven segment decoders, display drivers, a reference, and a clock. The ICL7106 is designed to interface with a liquid crystal display (LCD) and includes a multiplexed backplane drive; the ICL7107 will directly drive an instrument size light emitting diode (LED) display. The ICL7106 and ICL7107 bring together a combination of high accuracy, versatility, and true economy. It features auto zero to less than 10μV, zero drift of less than 1μV/°C, input bias current of 10pA (max) and rollover error of less than one count. True differential inputs and reference are useful in all systems, but give the designer an uncommon advantage when measuring load cells, strain gauges and other bridge type transducers. Finally, the true economy of single power supply operation (ICL7106), enables a high performance panel meter to be built with the addition of only 10 passive components and a display.

Para más detalles ver hoja de datos: ICL7107SCPL Datasheet.pdf (1007544)

The Intersil ICL7106 and ICL7107 are high performance, low
power, 31/2 digit A/D converters. Included are seven segment
decoders, display drivers, a reference, and a clock. The
ICL7106 is designed to interface with a liquid crystal display
(LCD) and includes a multiplexed backplane drive; the ICL7107
will directly drive an instrument size light emitting diode (LED)
display.
The ICL7106 and ICL7107 bring together a combination of
high accuracy, versatility, and true economy. It features
auto zero to less than 10μV, zero drift of less than 1μV/°C,
input bias current of 10pA (max) and rollover error of less than
one count. True differential inputs and reference are useful in
all systems, but give the designer an uncommon advantage
when measuring load cells, strain gauges and other bridge
type transducers. Finally, the true economy of single power
supply operation (ICL7106), enables a high performance panel
meter to be built with the addition of only 10 passive
components and a display.
